Imray - 2000 - Suffolk and Essex Coasts

We endeavour to sell only the latest versions of nautical charts that include the most recent updates.

Imray nautical charts use the meter as reference unit.

All Imray charts are now based on the WGS 84 reference system. Except for some Imray-Iolaire charts of the Caribbean Sea, all charts are in the metric system. Each chart includes reference system details and projection on which it is based, in order to be entirely safely used with GPS navigation systems.

Familiar to navigators, nautical charts have undergone intensive evolution over time. Whatever chart is used, precautions must be taken for safe use.

Pack :

The paper:
Imray has adopted Pretex, a support whose main characteristic is its resistance to use in humid conditions (rain, sea-spray), while still enabling easy writing and erasing of personal navigation data (position and route plotting, etc.).
This support is latex coated paper, which makes it highly resistant to folding, even when wet. This water resistance is not unlimited but provides the chart with satisfactory durability.

Imray charts coverage is divided into several series:

• West Europe, series C charts provide general coverage of the scale with large-scale charts incorporated.
• The Mediterranean, series G and M charts provide general coverage of the scale with charts incorporated.
• Atlantic and East caribbean, Imray - A, B, D, and E Iolaire series tables ensure general coverage of the scale with charts incorporated.

Sheet sizes :

• Serie C: 787 x 1118 mm (31" x 44")
• other series: 640 x 900 mm (25" x 35½")
• Series 2000 : A2 590 x 420 mm

Technical information:
Imray charts are designed for leisure boating with its cartography, containing a distinct colour coding system and a dense grid for easier plotting.

Inset:

Both sides print:

Reprint and updates:
Based on official update surveys, Imray charts are continuously overseen by the publisher, who monitors corrections, so that the charts are always as accurate as possible and ready for delivery.

Nautical charts are corrected up to the printing date; updates can be downloaded from the Imray website until a new edition is published. Once a new edition has been published, the previous edition cannot be corrected; it is considered dangerous for navigation and must be replaced.

A pack of 10 charts for the Suffolk and Essex Coasts. The pack includes:

• 2000.1 Suffolk and Essex Coasts (1:120 000)
• 2000.2 Rivers Ore and Alde (1:35 000)
• 2000.3 River Deben and Orford Haven (1:35 000)
  • 3A. Woodbridge (1:15 000)
  • 3B. Tide Mill Yacht Harbour (1:10 000)
• 2000.4 Harwich Approaches & Walton Backwaters (1:35 000)
  • 4A. Walton Yacht Basin & Titchmarsh Marina (1:24 000)
• 2000.5 Rivers Stour and Orwell (1:35 000)
  • 5A. Upper Orwell to Ipswich (1:20 000)
  • 5B. Fox's Marina (1:10 000)
  • 5C. Woolverstone Marina (1:10 000)
  • 5D. Suffolk Yacht Harbour (1:10 000)
  • 5E. Shotley Marina (1:10 000)
• 2000.6 River Blackwater (1:35 000)
  • 6A. Maldon (1:20 000)
  • 6B. Tollesbury Marina (1:12 500)
  • 6C. Bradwell Marina (1:12 500)
• 2000.7 River Colne (1:35 000)
  • 7A. Wivenhoe (1:20 000)
  • 7B. Brightlingsea (1:15 000)
• 2000.8 River Crouch Entrance (1:35 000)
• 2000.9 Rivers Crouch and Roach (1:35 000)
  • 9A. Fambridge Yacht Haven (1:10 000)
  • 9B. Bridgemarsh Marina (1:10 000)
  • 9C. Burnham Yacht Harbour (1:10 000)
• 2000.10 Orford Ness to Lowestoft (1:90 000)
  • 10A. Lowestoft Approaches (1:35 000)
  • 10B. Lowestoft Harbour (1:10 000)
  • 10C. Lowestoft ? Lake Lothing (1:10 000)
  • 10D. Southwold Harbour (1:12 500)

For this February 2018 edition the latest depth surveys have been applied. The latest wind farm information is included where relevant. There has been general updating throughout.

The 2018 edition is now wirobound and tidal stream information is included. Individual sheets of this atlas will no longer be sold separately. However, 1st edition charts Y2, Y6 and Y12 are to be published and are replicas of charts 2000.2, 2000.1 and 2000.5 respectively.

• Part Number: YOT0850
• Scale: 1:1(Various)
• ISBN: 9781846239748
• Manufacturer: Imray Laurie Norie And Wilson Ltd
• Publisher: Imray Laurie Norie And Wilson Ltd
• Author: Imray
• Edition: 2018
• Format: Folio - A2 Size
