We endeavour to sell only the latest versions of nautical charts that include the most recent updates.
Imray nautical charts use the meter as reference unit.
All Imray charts are now based on the WGS 84 reference system. Except for some Imray-Iolaire charts of the Caribbean Sea, all charts are in the metric system. Each chart includes reference system details and projection on which it is based, in order to be entirely safely used with GPS navigation systems.
Familiar to navigators, nautical charts have undergone intensive evolution over time. Whatever chart is used, precautions must be taken for safe use.
Pack :
The paper:
Imray has adopted Pretex, a support whose main characteristic is its resistance to use in humid conditions (rain, sea-spray), while still enabling easy writing and erasing of personal navigation data (position and route plotting, etc.).
This support is latex coated paper, which makes it highly resistant to folding, even when wet. This water resistance is not unlimited but provides the chart with satisfactory durability.
Imray charts coverage is divided into several series:
Sheet sizes :
Technical information:
Imray charts are designed for leisure boating with its cartography, containing a distinct colour coding system and a dense grid for easier plotting.
Inset:
Both sides print:
Reprint and updates:
Based on official update surveys, Imray charts are continuously overseen by the publisher, who monitors corrections, so that the charts are always as accurate as possible and ready for delivery.
Nautical charts are corrected up to the printing date; updates can be downloaded from the Imray website until a new edition is published. Once a new edition has been published, the previous edition cannot be corrected; it is considered dangerous for navigation and must be replaced.
A pack of 9 charts for the Dorset and Devon coasts. The pack includes:
On this edition the latest depth surveys have been included. The River Dart chart has been reschemed to show larger scale coverage of Kingswear and Dartmouth. For this edition tidal stream information is included. There has been general updating throughout.
Individual sheets of this atlas will no longer be sold separately. However, 1st edition charts of Y39, Y40 and Y41 have been published that replicate charts 2300.6 & 7, 2300.8 and 2300.10 respectively. These are part of our 'small format Y chart series' that mirror coverage from the corresponding atlas and are A2 size. For details of these please see the relevant page on our website.
A voucher code to download ID20 Imray English Channel charts into Imray Navigator (Imray app for iPad, iPhone and Android) is included with this atlas.
